Typographic Myth Busting: What’s a Ligature, Anyway?

If your work deals with typography in any way, you are very likely familiar with the term ligature. But the definition of this term is often unclear. There seems to be one problem in particular: We usually use the term when we want to talk about a certain kind of ligature, to which cases like fi and fl belong. Their use suggests, that there are “real” letters of the alphabet like a, b, c and then there are ligatures like fi and fl. People then assume, that when something is a ligature, it cannot be a “real” letter of the alphabet. But this is not true.

Defining the scope

The truth is, that the term ligature just means “connection” (from Latin ligari). The term itself doesn’t imply a certain purpose or use itself. Today, there are two possible ways to define a ligature and both ways can appear in connection or individually. If we talk about the appearance of type, a ligature is made from two or more letters, which appear connected. In hand writing such connections are created all the time.

But since the invention of moveable type, a new and more technical definition has appeared. When in metal typesetting two ore more letters are cast together to one sort, this is considered a ligature. This use in metal type has also transcended into the digital age. Ligatures are now usually included as single glyphs in a font, even though they might represent different characters in the underlying text.

Often these definitions of appearance and technical implementation occur in combination. For example, the the “f” and the “i” in the  fi ligature are visually connected and included as a single glyph in a font.

A typical typographic ligature as one glyph



But “f” and “i” might also appear connected, even if they are separated glyphs, just because the arc of the “f” extends over the right side bearing of the glyph. On the other hand, a type designer might create an fi ligature, where the unwanted collision is avoided by drawing an “f” with a shorter arc. Then “f” and “i” don’t appear connected, but they are still displayed using a ligature in the technical sense.

A technical ligature, where the letters appear optically unconnected



As we can’t judge a book by its cover, we also cannot always tell from the appearance of a text, whether or not ligatures have been used.

Classifying Ligatures

If its not clear from the context, it is a good idea to specify the types of ligatures we talk about. There are basically two main categories: typographic and orthographic ligatures.

Typographic Ligatures

These ligatures are just connected for typographic reasons. In today’s digital typesetting with smart-font technologies like OpenType we usually divide typographic ligatures in Standard Ligatures and Discretionary Ligatures. The first group of ligatures (fi/fi/ff/Th …) is usually applied by default, because they are considered an improvement of the text setting.
Discretionary Ligatures (ct, st …) are used as stylistic option, often used in headlines or logotypes. Note that typographic ligatures never affect the orthography of the underlying text. As the name suggest, they are purely typographic.

Orthographic Ligatures

These ligatures serve a very different purpose than typographic ligatures. The best example of this category is the letter w/W. It actually derived from a ligature of two V or U, which were not differentiated at that time. And that’s why this character is still called Double-U. From this example it should be clear, that it doesn’t make sense to make a distinction between “real” letters and ligatures. In contrast to typographic ligatures, orthographic ligatures are not optional. Even though they might be derived from a ligature historically— in today’s orthography of a certain country they only stand for themselves and cannot be separated like an fi ligature. They are treated like any other letter of the alphabet. And that’s why they also usually exist as a lowercase and uppercase version. Typical orthographic ligatures in the Latin script are w/W, æ/Æ and œ/Œ.

Orthographic Ligature or Digraph?

One (Dutch) letter and two very different ways to write it

But beside the obvious cases like Æ and Œ there are also some more complicated ones which usually cause confusion, even among typographers. Those cases are IJ/ij, DŽ/Dž/dž, NJ/Nj/nj, LJ/Lj,/lj. They do have a Unicode code point, so they can be used as one character/glyph. But it is also common to just type the individual characters, which is usually called a digraph. So what are they? A letter, a ligature or a digraph? From just viewing at printed text, we can’t even tell if one or two glyphs have been used. Just because we see two optically separated characters, doesn’t mean it was technically achieved this way.

What we can tell, is that they are an orthographic and phonetic unit. And there is a simple way to find out: just ask a literate native if these cases would fill one square in a crossword puzzle. If they do, it is safe to say, that they are considered letters of the alphabet. Whether or not they are typeset as one glyph (→ ligature) or two glyphs (→ digraph) is a purely technical or practical side note, that doesn’t affect the orthographic use or understanding of these letters. Some orthographic ligatures might have earned a spot on typewriter and later on computer keyboards, some orthographic ligatures might not.

In contrast, there are also digraphs which are never considered one letter. For example, in modern German there is the digraph ch/Ch/CH and even a trigraph (sch/Sch/SCH). So two or three letters represent just one sound, but those cases are never considered one letter when set in the Latin script—they fail the crossword puzzle check. So while the Dutch ij/IJ can indeed be considered a letter, the German ch/Ch/CH cannot. The latter are always considered individual letters.

The Very Special Case of the Letter ß

In such a discussion about letters, ligatures and digraphs one case always causes the most heated discussions: the German Eszett (ß). Many typographers and type designers insist, that the German ß is just a ligature, and they usually believe it is made from a combination of ſ and s. To put it simple: Those people are wrong. Let me straighten this out for you …

It is true, that there is an ſs ligature in (usually cursive) Latin writing and printing, that has been used for centuries. And today’s type designers often use this old design principle for designing their modern ß characters.

Looks like a modern ß, doesn’t it? But this Latin ligature is not the source of the German ß character. (Note that the example above isn’t set in German!) The real ß character developed in blackletter writing and there is no consensus yet, how it actually evolved. But while we don’t know for sure, how the ß character developed in blackletter writing, we know for sure, how the German ß in the Latin script came into being. And this is actually the source of the modern ß character we use today.

German was traditionally set in blackletter writing. Up until the end of the 19th century there was no standardized orthography and also no agreement how the special rules of blackletter typesetting would translate to the Latin script. This changed around 1900. First there were orthographic conferences which defined the first “official” German orthography and then another committee of printers, publishers and type founders had to agree on typographic issues following those orthographic decisions. And that’s when the Latin ß was “invented”.

Here is a scan from 1903 when the new Latin ß glyph was announced to type foundries and printers in Germany, Austria and Switzerland.

It was agreed, that German type foundries had to add a new letter to their Latin typefaces and out of many different design suggestions, the so-called Sulzbacher Form was chosen. The design (see image above) was selected because it bears resemblance to an ſ + z connection, but that is a purely stylistic choice. The Latin ß came into being as one character of the German alphabet at the beginning of the 20th century. It served a purely orthographic, not typographic purpose, just like the “w” is not an option for two “v” in the German or any other orthography.

The design principles of the ß character changed over the course of the 20st century. Some typefaces use the original Sulzbacher Form, some designers try to replicate the blackletter glyph and more and more type designers go for the connected ſs approach. But those are all purely stylistic decisions, as we can choose between different designs of “a” and “g”. It does not however, affect how these letters are understood and used orthographically. The letter ß came into the Latin script for German typesetting as a single glyph, introduced from one day to the next. Calling it a ligature is usually misleading, as the letter “w” is usually not called a ligature, despite its history.


Some key facts to take away:

  • When one talks about ligatures, it makes sense to differentiate between typographic and orthographic ligatures.
  • It also makes sense to point out, if one talks about the technical implementation or the appearance of a ligature.
  • What is considered a letter of the alphabet is defined by the orthography, not the appearance or the technical implementation. Therefore …
    • … the ß in modern German is still one letter, even if it looks like ligature
    • … the Croatian Dž is still one letter, even if it looks like two common glyphs and is typeset using two glyphs
Tagged as:

11 Comments

  1. Sergio 2012/11/21 at 1:09 AM #

    It’s hard to understand for me the purpose of having independent glyphs and unicodes for digraphs like IJ and DŽ as it’s not helpful if the user needs to alter the font’s tracking. I’m also wondering if this digraphs have their own space on their respective language keyboards.

    Thanks for the article! Herrmann.

  2. Paul Bies 2012/11/21 at 5:08 PM #

    Brilliant article on ligatures and those odd characters that I never use, not knowing what they mean.

    Thanks!

  3. Mark 2012/12/07 at 7:44 PM #

    As far as I know the ‘ß’ actually is considered two letters in German. The ‘ß’ is actually two letters. Originally either a combination of ‘ss’ or ‘sz’, nowadays it’s exclusively used as the ‘ss’ variant which some German-speaking countries prefer (Liechtenstein, and Switzerland if I’m not mistaken) It can only occur at specific locations in a word. A word can never start with a ‘ß’, and it is used to denote a verb-change of a word. Example: ‘schließen’ or ‘schliessen’. The ‘schlies’ is the root (‘close’) and the ‘-sen’ makes it ‘to close’.

    With the new spelling the use of the ‘ss’ variant was preferred. The Germans tried to introduce that spelling somewhere late nineties, but I have the idea it hasn’t really caught on yet.

  4. Ralf Herrmann 2012/12/07 at 7:51 PM #

    >>The ‘ß’ is actually two letters.

    No. Just as I explained: It’s as much two letters, as the W is considered two letters. And it’s this way at least over 100 years, when the first official German orthography was introduced.

    The orthographic use changed indeed in the 1990s. ß and ss are both a sharp s sound, but ß us used after long vowels, and ss after short vowels.

  5. Ralf 2012/12/16 at 12:03 PM #

    Unfortunately the ß fails your crossword test.

  6. Ralf Herrmann 2012/12/16 at 12:24 PM #

    It’s just meant to work one way: If it uses one square in a cross-word puzzle, it safe to say it is considered a letter of the alphabet. But if it uses more than one squares, that does not mean it cannot be considered one letter.

  7. Tomas 2012/12/24 at 2:16 AM #

    Another example: in Czech alphabet Ch is considered to be a single character. http://en.m.wikipedia.org/wiki/Czech_alphabet

  8. Joel Meyer-Hamme 2012/12/24 at 1:40 PM #

    The German letter ß has caused much confusion and it doesn’t help to look it up on Wikipedia since the English article http://en.wikipedia.org/wiki/ß isn’t entirely correct either.

    Given that the ß fails the crossword test it is helpful to understand the idea of an ‘umlaut’. They are variants of actual letters that became letters of their but are not conceived as members of the alphabet. Historically, they all were ligatures which they somehow aren’t anymor, as mentioned above. So the letter ‘a’ has the variant ‘ä’, o has ‘ö’, u -> ü and ß is a variant of s.

    All umlauts are proper letters, do not show up in the alphabet, can historically be seen as ligatures but became mere variants and are used for important differentiations of similar words in the Germann grammar. In crossword they are represented like this: ae for ä, oe for ö, ue for ü and ss for ß.

    I hope this clears things up a bit.

  9. Gunnar Bittersmann 2013/01/21 at 1:11 PM #

    @Mark:
    > Example: ‘schließen’ or ‘schliessen’.

    There’s no ‘schliessen’, except for CH and LI. ‘ie’ is a long vowel [iː], ‘ss’ does not appear after long vowels.

    > The ‘schlies’ is the root (‘close’) and the ‘-sen’ makes it ‘to close’.

    No. The root is either with ‘ß’ after long vowel as in infinitive ‘schließen’ or with ‘ss’ after short vowel as in participle ‘geschlossen’ or in noun ‘Schloss’, but never with single ‘s’.

    In old orthography (before 1996) ‘ss’ became ‘ß’ after short vowel at the end or before ‘t’: ‘Schloß’ (but ‘geschlossen’).

  10. Craig Eliason 2013/11/02 at 3:48 PM #

    “But since the invention of moveable type, a new and more technical definition has appeared.” So the word/concept itself predates moveable type? Or do you just mean that it might denote something different when making reference to letters that predate moveable type?

  11. Crissov 2013/11/13 at 1:57 PM #

    Actually, eszett became a letter in 1996, and about ten years later finally got its uppercase variant. The orthographic rules for choosing ‹ß› over ‹ss› during most of the 20th century – locally also applied earlier – are inherently typographic: It occurred exactly where the long ‹ſ› preceded a round ‹s› if these positional variants would be used, as is customary in blackletter type.
